• Rock chip RK3588 processor   • 7" LED display, visible under strong ligh • Built-in capacitive fingerprint recognition module • Some interfaces use aviation plug interfaces • Front and rear dual cameras, front 5MP, rear 8MP • Android, Linux system (optional)

RGD-TPC-AR0700T-0002A

Detail

TECHNICAL SPECIFICATIONS



ProcessorRock chip RK3588
MemoryLP DDR4 8GB
Storage

256GB EMMC (support TF card expansion)

OSAndroid, Linux system (optional)
Battery7000mAh
Display

7" LED backlight display, 1080 x 1920 resolution, maximum brightness ≥650,visible under strong light


Camera

Front: 5 MP (fixed focus, with light sensor), Rear: 8 MP (phase autofocus, with flash function)

Fingerprint Built-in capacitive fingerprint recognition module, supports more than 8 users
ColorArmy green/Ice grey/Navy grey/Black
Dimension

140.0mm x 200.0mm x 21.0mm

Materialmagnesium aluminum alloy
Weight0.7KG
Working Temperature-20℃ ~ +55℃, -40℃ ~ +65℃ optional
Storage Temperature-40℃~ +60℃
Humid Heat95%±3% alternating 30℃~60℃, 48h, no condensation (shut down)
Waterproof LevelMeet IP67 standard
Ports1*DC input, 1*Serial port, 2*USB2.0, 1*100M network port, 1*Precision connector interface (2*USB, 1*Network port 1*Serial port; 1*Charging), 1*The 4G/5G system encryption module interface and NFC interface are reserved, among which the 4G/5G system encryption module interface is an optional interface/reserved interface
