• Intel low-power 6th/7th/8th generation U-series processors
• Adopts capacitive touch screen and supports multi-touch
• SSD M.2 interface SATA, 256G
• Front and rear dual cameras, front 8MP, rear 5MP
• Windows7/10, Linux system (optional)
REQUEST QUOTE

RGD-TPC-AX1001T-0005

Detail

TECHNICAL SPECIFICATIONS



ProcessorIntel 6th/7th/8th generation U series processor
MemoryDDR4 8/16/32GB
Harddisk

SSD M.2 interface SATA, 256G, other capacities optional

OSWindows7/10, Linux system (optional)
Battery5000mAh
Display


10.1"display


Camera

Front: 8 MP, Rear: 5 MP

ColorArmy green/Ice grey/Navy grey/Black
Dimension

193.0mm x 274.0mm x 26.0mm

MaterialAluminum alloy, magnesium aluminum alloy (optional)
Weight1.7KG
Working Temperature-20℃ ~ +60℃, -40℃ ~ +65℃ optional
Storage Temperature-45℃~ +75℃
Humidity5%~95%RH
Waterproof LevelIP65 (front panel)
Ports

2*USB3.0, 1*SIM,   1*HDMI (Type A), 1*RJ45 10/100/1000M adaptive DC 15-28V (aviation plug), 1*3.5mm Audio Combo
