Low power consumption 6th/7th/8th generation,
U series processor
15.6-inch LCD display, 1920*1080 resolution Built-in 8,000mAh battery with long battery life Part of the interface using aviation plug interface
Windows Operating System

RGD-TPC-AX1506T-0001

Detail
Product Features:
1】Low power consumption 6th/7th/8th generation, U series processor
2】15.6-inch LCD display, 1920*1080 resolution
3】Built-in 8,000mAh battery with long battery life
4】Part of the interface using aviation plug interface
5】Windows Operating System
TECHNICAL SPECIFICATIONS:
ProcessorI5/I7 (6th/7th/8th generation U-series processors optional)
MemoryDDR4 8GB/16GB/32GB
HarddiskSSD 128G/256G/512G/IT (Optional)
Display15.6 inches LCD screen
Resolution1920*1080
GraphicsMXM1050M 4G
OSWindows OS
Battery8000mAh
Endurance Timearound 4 hours
PortsUSB3.0*2 USB port, HDMI*1, RS232/485*1(aviation plug) Serial port, HDMI*1, 1*RJ4510/100/1000M self-adaptation (aviation plug) Network Interface,1*DC power supply interface (input 100-240V output 19V 6.32A) Power supply interface, 1*audio
Dimension420*270*30mm
Cabinet ColorArmy green (optional)
Weight3.5KGs
Working Temperature-20℃ ~ +55℃
Storage Temperature-40℃~ +65℃
Humidity5～95%RH
Waterproof LevelIP65 (on the surface)
Electromagnetic Compatibility:
1, Meet MIL-STD-461G (EMC, EMI, EMS, ESD):
CE101 25Hz - 10kHz Conducted Emissions, Audio Frequency Currents, Power leads
CE102 10kHz -10MHz Conducted Emissions, Radio Frequency Potentials, Power leads
CS101 25Hz - 150kHz Conducted Susceptibility, Power Leads
CS106 Conducted Susceptibility, Transients, Power Leads
CS112 Electrostatic Discharge Susceptibility
CS114 4kHz -400MHz Conducted Susceptibility, Bulk Cable injection
CS115 Conducted Susceptibility, Bulk Cable injection, Impulse Excitation
CS116 10kHz - 100MHz Conducted Susceptibility, Damped Sinusoidal Transients, Cables and Power Leads
RE101 25Hz -100kHz Radiated Emissions, Magnetic Field
RE102 10kHz - 18GHz   Radiated Emissions, Electric Field
RS101 25HZ - 100kHz Radiated Susceptibility, Magnetic Field
RS103 10kHz - 40GHz Radiated Susceptibility, Electric Field
2, MIL-STD-810H (high and low wide temperature, low pressure, humidity, vibration, shock, salt spray, temperature shock, rain, dust, fungus, solar radiation etc.)
